Cement Silo
Specification:
- Capacity : Single Silo - 750 – 3500 CFT
- Twin silo – 2 X 1000 CFT
- Type : U-stamp, Non U-stamp
- Gravity discharge, Under pressure discharge
Application :
- Storage of Cement, Barite, Bentonite, etc
Construction :
- Steel - SA 36, 516 Gr.70, ST 52-3, Equivalent steel
Pipe lines :
- Fill / Vent / Discharge line – Terminated with Valves & Hammering unions/Customized
- Aeration system with Air jets / Aeration pad
Man ways :
- At bottom – For easy accessibility – Optional man way at top
Testing/Inspection :
- Tank weld joints – MPI / Radiography – As per client requirements
- Lifting lugs - Load test – MPI testing - Certified for empty lift - Witnessed by qualified third party
- Hydro test – As per working pressure – Witnessed by qualified third party
Accessories :
- Pressure relief valve
- Pressure gauge
- Ladder with bolted cage
- Provision for mounting compression load cell
External Finish :
- Grit blasting followed by three coat paint system
