| Specification |
Details |
| Capacity |
25 – 60 CBM |
| Application |
For transportation of dry sand, aggregate, rocks, other commodities |
| Shape |
V / Banana type self-supporting body |
| Construction |
- All steel welded construction – Steel A 36/ST 52-3/Equivalent
- Designed to operate under working pressure of above 2 Bar
- Both ends of the tank are dished
- Aeration system – Canvas hose with aluminum strip
- Safety accessories – Pressure relief valve, Pressure gauge, Non-return valve
- Discharge – Both sides of the tank with air hoses, shut off valves
- Man way at the top – 20”
- Walkway on the top with foldable handrail
- Axle – Multi leaf mechanical/air suspension – Tandem/Trident
- Tires – Twin tire fitment – As per load/terrain condition
- Brakes – Two line air brake system – Acting on all wheels – Automatic load sensing valve
- Landing gear – Two speed – Manual
- King pin – 2” or 3.5” – Interchangeable
- Electricals – 7 pin – 24V – Side lights, Reflectors, Reverse lights
|
| Compressor |
Air compressor – Piston type – With Deutz diesel engine |
| Accessories |
- Discharge hoses – Steel wired
- Spare wheel carrier
- Rear anti-run bumper
- Mudguards & mud flaps
- Toolbox & GRP water tank
|
| Finish |
Grit blasting followed by three coat paint system |
