| Specification |
Details |
| Capacity |
2X50 BBL – 2X60 BBL – 2X75 BBL – 2X100 BBL |
| Type |
Skid or Trailer mounted |
| Application |
- Uniform cement slurry blending, Mixing of slurries and other chemicals
- Suitable for Slurry, HCL (Up to 32% concentration), and other chemicals
|
| Engine |
- Engine package is mounted on vibration isolators
- Diesel operated – 300-350 HP – Controlled electronically – Caterpillar / Detroit / Other options
|
| Gear Box |
Funk / Other options |
| Hydraulic Pump |
Two numbers – Driven by hydraulic motors – Parker Denison / Other options |
| Centrifugal Pump |
Two numbers – 6 X 5 X 11 – Hydraulically driven |
| Agitator |
One number per tank – Driven by hydraulic motor – Poclain / Other options |
| Valves |
PTFE coated valve for acid application / Optional actuator operated |
| Manways |
One number on each tank – Hinged type |
| Level Indicator |
Engraved level indicator on each tank |
| Construction |
- Two number of tanks – Skid or Trailer mounted
- Steel – SA 36, 516 Gr.70, ST 52-3, Equivalent steel
|
| Skid |
Heavy duty – Top lifting hooks – Optional DNV certified – 2.7.1 |
| Trailer |
- Axle – 2X12/15 Ton – Mechanical suspension – Under slung
- Tires – 315/80 R 22.5 – Selection depend on load/terrain condition
- Brake – Two line air brake system, Spring assisted brakes
|
| Internal Coating |
- Epoxy primer, Coal tar epoxy for Slurry application
- Derakane (411-45 or 470-300) or Rubber lining for HCL and other highly corrosive chemicals
|
| External Finish |
Grit blasting followed by three coat paint system |
