| Specification |
Details |
| Capacity |
300 BBL – 500 BBL |
| Shape |
- A. Bottom round & top flat
- B. Bottom & Top round
- C. Bottom “V” & top flat
|
| Compartment |
Single or Multiple compartment |
| Application |
Suitable for Slurry, Water, HCL (Up to 32% concentration), Crude oil, and other chemicals. |
| Construction |
- Steel – SA 36, 516 Gr.70, ST 52-3, Equivalent steel
- Axle – 12/15 Ton – Mechanical suspension – Under slung
- Tires – 11 R 22.5
- Brake – Two line air brake system, Spring assisted brakes
|
| Pipe Lines |
- Fill line – With Valves & Hammering unions – One or Two – As per client requirements
- Discharge Manifold (6”/8”/10”) – 2-4 number of outlets – With Valves & Hammering unions
- Vent line – One number per compartment – With Valves & Hammering unions
- Drain line – One number per compartment – With Valves & Hammering unions
|
| Man Ways |
Minimum 2 numbers – One at bottom and one at top for easy accessibility |
| Level Indicator |
- PVC dipstick with maple wood
- Sight glass – Magnetic level indicator
|
| Internal Coating |
- Epoxy primer, Coal tar epoxy for Water & Slurry application
- Derakane or Rubber lining for HCL and other highly corrosive chemicals
|
| External Finish |
Grit blasting followed by three coat paint system |
