| Specification |
Details |
| Capacity |
6000 – 12000 IG |
| Shape |
Elliptical, Double-D or Customized |
| Compartment |
Single or Multiple compartment |
| Application |
For transportation of Diesel, Petrol, Crude oil etc. |
| Construction |
- Steel – SA 36/ST 52-3/Stainless Steel/Aluminum/Equivalent steel
- Axle – Tandem/Trident – Mechanical/Air suspension – Under slung/Over slung
- Tires – Subject to Load/Terrain
- Brake – Two line air brake system, Optional ABS/EBS/Emergency/Spring assisted brakes
|
| Pipe lines |
- Top or Bottom loading
- Fill line – Customized as per client requirements – With Valves & Unions
- Discharge line – Customized as per client requirements – With Valves & Unions
- Vapor Recovery line – Optional
|
| Man ways |
Quantity as per number of compartment for easy accessibility |
| Safety devices |
- Pressure & Vacuum relief valves
- Optical sensor to avoid spill over
- Emergency shut off
- Vent line & Spill over tray connected to optional scrubber tank
- Optional tanker over turn protection
|
| Level Indicator |
- PVC/Aluminum dipstick
- Sight glass – Magnetic level indicator
|
| Internal Coating |
Epoxy primer/Diesel wash |
| External Finish |
Grit blasting followed by three coat paint system |
