Vacuum / Sewage Tanker

Specification	Details
Capacity	1000 – 5000 IG
Application	For transportation of Sewage water, Treated water, etc.
Shape	Cylindrical with outer rings for stiffening
Construction	All welded steel construction – Steel – SA 36/ST 52-3/Equivalent steel
Electricals	Side lights, Reflectors, Reverse lights
Pump	PTO driven vacuum pump
Door	Full open type – With hinges at driver side at rear – Secured with a set of clamps Sealed with neoprene rubber – Provision of greasing for clamp lubrication
Safety Equipment	Pressure & Vacuum relief valve – To control pressure and vacuum inside tank Primary & Secondary cut off – To prevent water entering inside pump Combination gauge – Showing pressure and vacuum inside tank
Accessories	Level Indicator – Sight glass – Showing level of content inside tank Optional 20” inspection manway Spare wheel carrier to accommodate spare tire Side & Rear anti-run bumper Mudguards & Mud flaps Toolbox & GRP Water tank Hose box with fill & discharge hoses – On either side of the tank
Finish	Internal: A. Grit blasting – SA 2.5 B. Epoxy / Coal tar coating – Two coats External: A. Grit blasting – SA 2.5 B. Epoxy primer followed by two coats of paint

Vacuum / Sewage Trailer

Specification	Details
Capacity	1000 – 5000 IG
Application	For transportation of Sewage water, Treated water, etc.
Shape	Cylindrical with outer rings for stiffening
Construction	All welded steel construction – Steel – SA 36/ST 52-3/Equivalent steel
Electricals	Side lights, Reflectors, Reverse lights
Pump	PTO driven vacuum pump
Door	Full open type – With hinges at driver side at rear – Secured with a set of clamps Sealed with neoprene rubber – Provision of greasing for clamp lubrication
Safety Equipment	Pressure & Vacuum relief valve – To control pressure and vacuum inside tank Primary & Secondary cut off – To prevent water entering inside pump Combination gauge – Showing pressure and vacuum inside tank
Accessories	Level Indicator – Sight glass – Showing level of content inside tank Optional 20” inspection manway Spare wheel carrier to accommodate spare tire Side & Rear anti-run bumper Mudguards & Mud flaps Toolbox & GRP Water tank Hose box with fill & discharge hoses – On either side of the tank
Finish	Internal: A. Grit blasting – SA 2.5 B. Epoxy / Coal tar coating – Two coats External: A. Grit blasting – SA 2.5 B. Epoxy primer followed by two coats of paint
