| Specification |
Details |
| Capacity |
20 – 60 CBM |
| Certification |
U-stamp, Non U-stamp |
| Construction |
- Steel – SA 36, 516 Gr.70, ST 52-3, Equivalent steel
- Axle – Tandem / Trident axle – Mechanical suspension
- Tires – Suitable for load / terrain condition
- Brake – Two line air brake system, Spring assisted brakes
- King pin – 2” – JOST – Interchangeable with 3.5”
- Landing Leg – JOST – 2 Speed
- Electricals – 7 pin – 24V – Side lights, Reflectors, Reverse lights
|
| Pipe Lines |
- Fill / Vent / Discharge line – Terminated with Valves & Hammering unions/Customized
- Aeration system with Air jets / Aeration pad
|
| Man Ways |
One number on each silo – At top for easy accessibility |
| Compressor |
Air compressor – Piston type – With Deutz diesel engine |
| Aeration System |
Jet or pad system |
| Testing/Inspection |
- Tank weld joints – MPI / Radiography – As per client requirements
- Lifting lugs – Load test – MPI testing – Certified for empty lift – Witnessed by qualified third party
- Hydro test – As per working pressure – Witnessed by qualified third party
|
| External Finish |
Grit blasting followed by three coat paint system |
