| Specification |
Details |
| Capacity |
25,000 – 45,000 LITERS |
| Application |
For transportation of Drinking water, Non-drinking water, Salt water, Agricultural water |
| Shape |
Elliptical, Double D-shape, Other Customized shapes |
| Construction |
- All welded steel construction – Steel – SA 36/ST 52-3, Equivalent steel
- Man way – 20” – With filling hatch – Minimum 2 Nos.
- Vent – Separate vent for proper ventilation – 2 Nos.
- Foldable hand rail with walkway
- Optional spray bar with nozzles
- Axle – Multi leaf Mechanical suspension – Tandem/Trident
- Tires – Twin tire fitment – As per Load/Terrain condition
- Brakes – Two line air brake system – Acting on all wheels – Automatic load sensing valve
- Landing gear – Two speed – Manual
- King pin – 2” or 3.5” – Interchangeable
- Electricals – 7 pin – 24V – Side lights, Reflectors, Reverse lights
|
| Pump |
- Diesel or Petrol Engine driven – Mounted on tanker chassis
- PTO driven pump – Mounted on prime mover
|
| Accessories |
- Spare wheel carrier to accommodate two spare tires
- Side & Rear anti-run bumper
- Mudguards & Mud flaps
- Tool box & GRP Water tank
- Hose box with fill & discharge hoses – On either side of the tank
|
| Finish |
- Internal:
- A. Grit blasting – SA 2.5
- B. Epoxy coating – Two coats – To suit content
- External:
- A. Grit blasting – SA 2.5
- B. Epoxy primer followed by two coats of paint
|
